QUICK RDS 1562

Description

The RDS 1562 remote panel is an instrument which allows to monitor the status and to set some parameters of the SBC NRG+ series QUICK battery chargers by means of the CAN BUS communication interface.

Key features:
– Alphanumeric LCD display
– Multi-language user interface
– Displays at the same time the three output voltages of the battery charger
– Display the total current supplied by the battery charger
– Displays which can be set on 6 different intensity levels
– Display contrast which can be set on 5 intensity levels
– Buzzer used for acoustic signaling
– Possibility of setting the parameters on the battery charger (CAN parameters excluded)
– Universal power supply (12/24 Vdc)
– CAN bus interface for data transfer
– Easy installation
– Can work in a wide range of ambient temperatures
– Reverse polarity protection
