QUICK RDH 1660

Description

The RDH remote panel is an instrument which allows to monitor the status of HSI inverter by means of a CAN BUS interface.

Features:
– Alphanumeric LCD display
– Multi-language user interface
– Display of the inverter power supply voltage
– Display of the inverter output voltage
– Display of the inverter output power
– Display backlight which can be set on 6 intensity levels
– Display contrast which can be set on 5 intensity levels
– Buzzer used for acoustic signaling
– Ability to change the operating mode and parameters of the inverter
– Universal power supply 12/24 Vdc (power supply via CAN1 port of the inverter)
– CAN bus interface for data transfer
– Easy installation
– Can work in a wide range of ambient temperatures
– Reverse polarity protection
